Inverter Dc Arc Welding Machine – Real Force ARC-400H High Voltage 440

MODEL ARC-400H
Input power voltage (V) AC440 ±15% (3 Ph)
Input power capacity (KVA) 12.3
Input voltage frequency (Hz) 50/60
No load voltage (V) 60
Output current (A) 20-380
Arc force current (A) 0-200
Output voltage (V) 25.2
Duty cycle (%) 60
Efficiency (%) 85
Insulation class F
Weight (kg) 25
Dimensions (mm) 565x 306 x 432
Protection class IP21S
Weldable (mm) 2.5 – 4.0



OPTIONAL :
– Electrode Holder
– Earth Clamp
– Welding Cable
– Scratch TIG Torch
– Argon Regulator
– Current Remote Controller



AVAILABLE ACCESSORY :
– Cable Connector Standard 2 pcs 35/50
Category:

Description

– DC inverter arc welder for SMAW / MMA / STICK welding or scratch GTAW / TIG / ARGON welding.
– Easy arc-starting with arc force and anti-sticking functions.
– Smooth and stable welding performance featuring minimal spatter.
– Automatic over-voltage and   over-current protection
– Auto compensation for voltage fluctuation.
– The size and weight of these machines make them portable
– and therefore ideal for site applications
– Suitable for welding all types of acid and basic types of electrodes.
– Small size, lightweight, high-quality construction, and power saving.
