15 Gallon, 1 Shelf, 2 Door, Manual Close, Flammable Liquid Cabinet – FC 1915
Specification Product :
- Reinforced double wall construction with 1-1/2 in (3.8 cm) air space on the sides, top, bottom, back, and doors
- constructed of 18-gauge steel
- The lead-free, high-gloss, baked-on powder finish
- Continuous piano hinges
- Ground connection
- Four adjustable galvanized leveling legs
- Trilingual warning labels
- 2 in. (5.1 cm) raised leakproof sill
- Patented adjustable galvanized steel shelves direct spills to the back and bottom of the leakproof sump and hold 350 lbs. (158.8 kg) Uniform Distributed Load (UDL)
- Internal and externally welded construction
- Two 2 in. (5.1 cm) internal vents with a fire baffle and cap
- Flush-mounted door handle with key lock
- three-point stainless steel bullet latching system
- 3 in. (7.6 cm) centers for shelf brackets
- Self-latching doors
- Door closing: manual close (180° opening)
Description
15-gallon, manual close, Add-On Flammable Liquid Safety The cabinet is constructed of 18-gauge (1 mm) steel. The sides, top, bottom, and doors are double-walled with a 1-1/2 in (3.8 cm) air space between walls. includes two vents, each with 2 in (5.1 cm) threaded fittings, and a fire baffle and cap. Cabinets have a high gloss powder coat finish with a red trilingual warning, plus a grounding attachment, a 3-point latch system, and a 2-in (5.1 cm) raised leakproof door sill. Each shelf is adjustable on 3 in (7.6 cm) centers, supported by 4 brackets, with a 350 lbs (159 kg) safe allowable load. Cabinets are FM-approved and meet NFPA Code 30 and OSHA requirements.
MODEL |
COLOUR |
FC-1915 YELLOW |
YELLOW |
FC-1915 WHITE |
WHITE |
FC-1915 RED |
RED |
FC-1915 GRAY |
GRAY |
