• High matching accuracy: unfitness of butt joint is below 1.5mm • Simple operation: single diameter design produce,no need to adjust. • Area adjust system: area adjust unfitness of butt joint,light,reasonable,reliable. • Light weight:easy to carry. • Manual lever type external pipe line-up champ–it is mainly used on pipelines with a diameter below 406mm.The main features are easy handling and high matching efficiency. • Manual rectangle screw-rod-type external pipe line-up clamp–it is mainly used for 16”-48” pipes during pipeline construction
Our Pipe Rack System is a special custom design and build automatic modular welding and transfer line process that incorporates a welding station with a fit-up, making it suitable for circumferential sub-welding tubular sections. It also consists of a hydraulic kicker to allow lifting and unloading. The Pipe Rack System assists customers in increasing production efficiency and reduces production costs in the long term.
• Welding, cutting, and grinding through clamping rotation and tilting the pipes. For automated operation with a two-dimensional adjustable torch clamping system to increase productivity. • Able to hold pipes with elbows, tee pieces, or other offset loads. • 3 sets of clamping rollers are renewable and able to supply special clamps or clamp rollers for workpieces with small clamping space. • Wide range of pipes can be clamped, rotary speed will not be affected by the diameter of the pipes. • Very convenient, quick precise centering and clamping, and works without a chuck. • Floating clamp device is able to clamp and rotate workpiece with unfavorable sphericity • Rigid structure, good integrity and can be conveniently transited, driving unit can be protected inside the bracket of the machine (eg. rotate/tilt unit). • ±40°tilt function allows the pipe–flange to implement fillet welding in a flat position. • We can also reserve an interface to connect the foot switch welding mask to control the workpiece, with the help of the pendant
